t-USE is a universal shell element that is manufactured in series as a prefabricated part and can be used for various applications in both building construction and civil engineering. Due to the prefabrication and the special shape of the support plates, CO2-friendly constructions with low resource consumption are possible.

High-performance prefabricated parts made of UHPC with material-appropriate planning should shape future construction activities.

Advance is not the improvement of what was but the focus on what will be in the future.

The basic element is a support plate with any shaped floor plan and an arbitrarily arranged folding edge. The plane-parallel cross-section has a thickness of only 30 to 50 mm or, in the case of prestressing, of only 50 to 60 mm. Despite the very thin-walled components, the low permeability means that very durable constructions can be implemented in many possible applications, especially when they are exposed to the elements. In most cases it is even possible to do without an additional moisture proofing.

® Use the advantages of this type of construction to make your ideas and conceptions of spatial structures a reality.

® The page shows you some suggestions and possibilities of this innovative building system t-USE.

® Contact us if you have any questions so that we can support you.

® If you want to make this universal shell element yourself or see it as an addition to your portfolio, then contact us. We enable you to obtain regional property rights.



Resource-saving designs with minimal CO2 consumption are a priority for us.



For our developments we use:

Knowledge, experience and creativity

Our patent KSA >click here<
